SW2-66kV Outdoor Minimum Oil Circuit Breaker: 66kV/72.5kV, CY5 hydraulic/CD5 electromagnetic/CQ pneumatic mechanism, automatic reclosing, free tripping, anti-pollution type, transmission distribution, -30°C to +40°C, GB1984/IEC.
Advanced SW2-66kV Outdoor Minimum Oil Circuit Breaker Series: Three-phase AC 50Hz outdoor high-voltage power equipment rated 66kV (72.5kV abroad) mainly used for control and protection of transmission and distribution lines, different operating mechanisms including SW2-60Ⅰ with CY5 hydraulic mechanism performing slow action/fast action/one-time automatic reclosing, SW2-66Ⅱ/Ⅲ equipped with CD5-370X electromagnetic mechanism or CQ-300A pneumatic mechanism enabling hydraulic jack manual slow action/electric quick action/one-time automatic reclosing with free tripping performance, side-mounted mechanism option reducing floor space, SW2-66ⅢL type for no-load long lines special requirements, ordinary type and anti-pollution type available, meets GB1984-89 and IEC standards.
Multiple Mechanism Options and Anti-Pollution Features: SW2-66kV incorporates CY5 hydraulic mechanism for Types Ⅰ and Ⅱ providing slow action/fast action/automatic reclosing capabilities, CD5-370X electromagnetic mechanism or CQ-300A pneumatic mechanism for Type Ⅲ offering hydraulic jack manual operation/electric quick action/automatic reclosing with free tripping performance, side-mounted mechanism configuration optimizing installation space, anti-pollution type with specific creepage distance >25mm/kV for harsh environments, ordinary type with >17mm/kV creepage distance, operates reliably in -30°C to +40°C ambient temperature, altitude ≤1000m, wind speed ≤35m/s, earthquake intensity ≤8°, providing reliable minimum oil circuit breaking solution for 66kV/72.5kV transmission distribution systems.
| SW2-66kV Outdoor Minimum Oil Circuit Breaker Specifications | Parameter | Unit |
| Brand | Bepto Insulation Systems | – |
| Model Number | SW2-66 (SW2-72.5 Abroad) | – |
| Product Series | SW2-60Ⅰ / SW2-63Ⅱ / SW2-66Ⅲ / SW2-66ⅢL | – |
| Product Type | Outdoor Three-Phase AC 50Hz High Voltage Minimum Oil Circuit Breaker with Hydraulic/Electromagnetic/Pneumatic Mechanism for Transmission and Distribution Lines | – |
| Core Technology | Minimum Oil Circuit Breaking + CY5 Hydraulic Mechanism (Types Ⅰ and Ⅱ) + CD5-370X Electromagnetic Mechanism (Type Ⅲ) + CQ-300A Pneumatic Mechanism (Type Ⅲ) + Slow Action + Fast Action + One-Time Automatic Reclosing + Free Tripping Performance + Side-Mounted Mechanism Option + Hydraulic Jack Manual Operation + Electric Quick Action + Anti-Pollution Type + Ordinary Type | – |
| Rated Voltage | 66kV (72.5kV Abroad) | kV |
| Rated Frequency | 50 | Hz |
| Phases | Three-Phase | – |
| Installation Type | Outdoor | – |
| Minimum Oil Technology | Yes (Minimum Oil Circuit Breaker) | – |
| CY5 Hydraulic Mechanism | Yes (Types SW2-60Ⅰ and SW2-63Ⅱ) | – |
| CD5-370X Electromagnetic Mechanism | Yes (Type SW2-66Ⅲ) | – |
| CQ-300A Pneumatic Mechanism | Yes (Type SW2-66Ⅲ) | – |
| Slow Action | Yes (CY5 Hydraulic Mechanism) | – |
| Fast Action | Yes (CY5 Hydraulic Mechanism) | – |
| One-Time Automatic Reclosing | Yes (All Mechanism Types) | – |
| Free Tripping Performance | Yes (Type SW2-66Ⅲ with CD5/CQ Mechanism) | – |
| Hydraulic Jack Manual Operation | Yes (Type SW2-66Ⅲ for Manual Slow Action) | – |
| Electric Quick Action | Yes (Type SW2-66Ⅲ) | – |
| Side-Mounted Mechanism | Yes (Option to Reduce Floor Space) | – |
| No-Load Long Lines Type | Yes (SW2-66ⅢL for Special Requirements) | – |
| Ordinary Type | Yes (Standard Type) | – |
| Anti-Pollution Type | Yes (For Harsh Environments) | – |
| Specific Creepage Distance – Ordinary Type | >17 | mm/kV |
| Specific Creepage Distance – Anti-Pollution Type | >25 | mm/kV |
| Standards Compliance | GB1984-89 (Equivalent to IEC Standard) | – |
| Control and Protection | Yes (Control and Protection of Transmission and Distribution Lines) | – |
| Transmission and Distribution | Yes (Mainly Used for Transmission and Distribution Lines) | – |
| Ambient Temperature | -30°C to +40°C | °C |
| Altitude | ≤1000 | m |
| Wind Speed | ≤35 | m/s |
| Earthquake Intensity | ≤8 | ° |
| Key Advantages | Minimum Oil Technology, Multiple Mechanism Options (CY5 Hydraulic/CD5 Electromagnetic/CQ Pneumatic), Automatic Reclosing, Free Tripping, Side-Mounted Mechanism, No-Load Long Lines Type, Anti-Pollution Type, Wide Temperature Range, GB1984/IEC Compliance | – |
| Primary Applications | 66kV/72.5kV Transmission and Distribution Lines, Control and Protection, No-Load Long Lines, Harsh Environments with Pollution, Three-Phase AC 50Hz Systems, Outdoor High Voltage Power Equipment | – |
